ADH Technology Co. Ltd.



GPS tracker

* Small compact design for long standby time and hidden surveillance tracking

* Quad-band 850/900/1800/1900MHz GSM modem

The GPS is integrated inside the 2G Module.

GNSS engine (GPS and GLONASS) with A-GPS (Offline and Online).

* Save and Auto Resend up to 16065 locations

* Built in motion switch (activated by G-Force)

* 1 negative inputs (active low to activate input).

* External +5Volt to +7Volt DC input power for Battery Charge

* Build in battery charger circuit

* Microphone connection

* Digital Temperature (option) and Humidity sensor (option)

* Serial RS232 port (1 * 9600 baud Rate) for external communication, Operating System upgrade and configuration settings upload)

* Wake up by time interval, Motion or movement or Input activation.

* Operating temperature range -40 deg. C to +85 deg. C  (Battery 0 – 60 deg. C)
